NO. MODEL TYPE AMOUNT OF EACH TREATMENT AMOUNT OF EACH HOUR 1 FVC-01S Single Bin Model 150 kg 300 kg 2 FVC-01P Single Pallet Model 450 kg 900 kg 3 FVC-02P Two Pallet Model 900 kg 1800 kg 4 FVC-04P 4 Pallet Model 1800 kg 3600 kg 5 FVC-06P 6 Pallet Model 2700 kg 5400 kg 6 FVC-08P 8 Pallet Model 3600 kg 7200 kg 7 FVC-10P 10 Pallet Model 4500 kg 9000 kg 8 FVC-12P 12 Pallet Model 5400 kg 10800 kg ※ Focusun professional R&D team will design the specific vacuum cooler for your special requirements.
Tailor made options available:
- Door : A. Standard swing door B. Horizontal sliding door
- Condensing type: A. Air cooling condenser B. Water cooling condenser C. Evaporative cooling condenser
- Refrigeration system: A. Freon system (R404a) B. Ammonia system
- Chamber material: A. Painted mild steel B. Stainless steel
- Additional options available: A.. Hydro cooling system B. Pulley loading system
-
Features and benefits of Vacuum cooler:
- Hydro vacuum cooler: designed with additional water circuit to meet the rapid cooling while to avoid excessive moisture loss.
- Uniform cooling: cool down the temperature inside and outside the products in a consistent steady and uniform way.
- High accuracy: equipped with imported digital display temperature and humidity controller, which can accurately control the vacuum and humidity, ensuring excellent tolerability and operation of vacuum cooler.
- Easy to operate: PLC screen control, automatically stop the cooling process when the pressure and temperature reach the number settled. Equipped with remote control and monitoring equipment which facilitate the operation and quickly resolve equipment failures.
-
Vacuum Cooler for Flowers
Once the flowers are cut, they should be pre-cooled immediately to reduce the physiological activities and ethylene release. Flower vacuum cooling technology controls the vacuum level during the pre-cooling process to control the temperature and humidity in vacuum chamber. Moreover, the vacuum level is related to the physiological characteristics, sensitivity, humidity and also the capacity of vacuum cooler. The average moisture loss is one-percent for each ten-degree Fahrenheit temperature drop. For those flowers which need be cooled to ultra-low temperature, Focusun provide hydro vacuum cooler to avoid excessive moisture loss and keep the freshness.
Application: all kinds of flowers, especially those with high respiration, such as roses and carnations.
